DPA 4088-F Headband Microphone (Beige)
DPA 4088-F Headband Microphone (Beige)
- Price listed is DAILY RENTAL rate.
Couldn't load pickup availability
Rent Headband Microphone DPA
DPA Microphones 4088 is a miniature cardioid headband built on the finest DPA experiences in microphone design and manufacturing, providing the best sounding directional headworn microphone available today for performing talent of various sorts. Open, natural and reliable are the most describing words for this microphone. The high quality of the microphone itself means, that you will hear the sound of the voice right away - not the microphone. In acoustically demanding live performance environments, where background noise and feedback is a concern, the 4088 will tackle these challenges with ease.
The smooth and elegant design of the 4088 makes it the most invisible headworn cardioid microphone today. Sound quality, visual elegance and versatility go hand in hand to transform every show into the performance of a lifetime. The capsule is a pre-polarized first order pressure gradient transducer, hidden in a small and lightweight housing with dimensions just slightly larger than our omni capsules. T he mechanical design is based on the proven build quality of the 4066 headband microphone. The headband mount is exactly the same; the boom however is 3 centimeters longer, to be able to match the need for placement at the corner of the mouth. The flexibility and stability of this construction is unique and has no equal.
Winner of the coveted PAR Excellence Award 2005 for innovation, value and performance.
Specifications:
- Principle of operation: pressure gradient
- Cartridge type: pre-polarised condenser element with vertical diaphragm
- Power supply: min 5 V - max. 50 V through the adapter system from DPA microphones
- Frequency range, ± 2 dB: 100 Hz - 20 kHz (±2 dB between 500 Hz and 20 kHz; 4-6 dB soft boost at 15 kHz)
- Directional characteristics: cardioid
- Equivalent noise level A-weighted: Typ. 26 dB (A) re 20 mPa
- Sensitivity, nominal, ±2 dB: 6 mV/Pa
- Equiv. noise level ITU-R BS.468-4: Typ. 38 dB (max. 40 dB)
- Capsule diameter: 5.5 mm (0.25 in)
- Total harmonic distortion (THD): <1% THD up to 123 dB SPL peak, <1% THD up to 120 dB SPL sine
- Cable drive capability: up to 300 m (984 ft)
DPA Microphones 4088 specs
| Polar Pattern | Cardioid |
| Principle of Operation | Pressure gradient |
| Cartridge Type | Pre-polarized condenser element with vertical diaphragm |
| Frequency Range | 100 Hz to 20 kHz (4 to 6 dB soft boost at 15 kHz), ± 2 dB |
| Sensitivity | 6 mV/Pa, -44 dB re. 1 V/Pa (nominal, +/-3 dB at 1 kHz) |
| Equivalent Noise Level | A-Weighted: Typical: 26 dBA re. 20 µPa Maximum: 28 dBA ITU-R BS.468-4: Typical: 38 dB Maximum: 40 dB |
| S/N Ratio | 68 dBA, 1 kHz at 1 Pa (94 dB SPL): |
| Total Harmonic Distortion (THD) | <1% THD up to 123 dB SPL peak <1% THD up to 120 dB SPL RMS sine |
| Dynamic Range | Typical 97 dB |
| Maximum Sound Pressure Level (SPL) | Peak Before Clipping: 144 dB |
| Output Impedance | 30 to 40 Ω |
| Cable Drive Capability | Up to 984' (300 m) |
| Connector | Microdot termination |
| Temperature Range | 14 to 113°F (-10 to 45°C) |
| Cable Length | 3.9' (1.2 m) |
| Dimensions (Ø x L) | 0.25 x 0.50" (5.40 x 11 mm) |
| Weight | 0.5 oz (14 g) |
