Rane Seventy-Two MKII DJ Mixer
Rane Seventy-Two MKII DJ Mixer
- Price listed is DAILY RENTAL rate.
The RANE SEVENTY-TWO MKII battle-ready 2-channel DJ mixer with multi-touch screen and Serato DJ is a 2-channel, advanced control and performance mixer that unleashes the full creative power of Serato DJ Pro software. The RANE SEVENTY-TWO MKII redefines the scope and possibilities for Pro, Club and Scratch DJ/turntablists with a feature set geared for liberated performance capability: a full-color touchscreen for immediate feedback of all critical performance functions; stackable Serato and Flex FX; MAG FOUR Faders; external and internal crossfader tension adjust controls; custom parameter control for instant doubles, silent cue and sync; dual DVS inputs; plus, the ultimate in expressive playback control via 16 multi-function trigger pads. Your performance insists on nothing short of perfection, so revolutionize your setup with RANE’s latest evolution of DJ battle tools and take your performance one step further.
Winning Heritage
The original SEVENTY-TWO is no stranger to high-profile performances, having proven itself time after time in extreme high-pressure performances to give DJs the winning edge–from DMC, Red Bull 3Style & the Goldies, the SEVENTY-TWO graced them all. With its robust solid build and reliability, paired with its unrivaled integration into Serato DJ Pro, it’s no surprise the SEVENTY-TWO is the champions choice of mixer.
MAG FOUR Faders
In addition to an ultra-intuitive layout primed for any performance setting, plus an external crossfader tension adjust, the SEVENTY-TWO MKII comes complete with three ultralight MAG FOUR faders. This design is Rane's lightest yet, and delivers high-quality patented technology, along with an external crossfader tension-adjust.
FEATURES:
- (3) MAG FOUR faders with reverse, contour and cut-in adjustment
- External and internal crossfader tension adjust controls
- Toggle Instant Double/Silent Cue/Sync controls
- Dual DVS inputs–AUX or phono/CD
- Solid steel construction—built like a tank for non-stop, heavy-duty use
- 4.3" touchscreen for moving wave display, FX control, song selection and user customizations
- Dual Flex FX engines, one for each channel
- Advanced Serato control: Chain-integrated Software Effect, plus one internal Flex Effect per channel
- Dual USB connections for DJ handoffs
- 16 Akai MPC-style performance pads, independent mode controls per deck
- Two microphone inputs–combo Neutrik, on/off, tone, mic/line level switches
- RCA session Inputs/outputs, balanced XLR, Main Out, balanced 1/4", Booth Out
- USB controller inputs for RANE TWELVE Battle Controller
- Serato DJ Pro DVS license, Pitch 'n' Time plus Serato DVS vinyl included
- Scratch Bank support with the release of Serato DJ Pro 2.4.3
Rock Solid
With the strength and durability of solid steel and aluminum casing, the gig and battle-ready SEVENTY-TWO MKII mixer represents the ultimate in advanced control needs and performance expectations of today’s DJs. Designed in collaboration with leading turntablists around the world and with the foundation of a globally trusted Seattle, U.S.-based engineering heritage, the SEVENTY-TWO MKII redefines what is possible when true DJ artistry meets groundbreaking technology.
Visualize the Mix
The SEVENTY-TWO MKII’s 4.3" color touchscreen interface relays Serato DJs moving waveforms, enabling navigation, track selection and extensive performance preference adjustment. It also offers full FX control and sonic manipulation utilizing and stacking the SEVENTY-TWO MKII’s dual Flex FX engines with Serato DJ Pro’s extensive effects banks.
Ready for Anything
Two DJ’s can perform simultaneously and handover effortlessly via the unit’s dual-USB connections. Turntablists can cut, flare, chirp, crab, orbit and transform with the new, tactile and precision-based MAG FOUR faders, then flip between creative control functions via the 16 MPC-style pads with RGB backlight and multi-performance mode selections. Also, Serato’s expressive Pitch ‘n Time DJ expansion is included free with the SEVENTY-TWO MKII, for DJs to integrate creative "pitch-play."
Serato Scratch Banks
Serato’s Scratch Bank is now supported on the SEVENTY. Access up to 32 different samples or tracks at the push of a button for instant scratching or mixing. Download of Serato DJ Pro version 2.4.3 from Serato's website is required.
SPECIFICATIONS:
Digital Audio
- Converters
- AKM High Definition Audio: 24-bit PCM, 48kHz
- Digital Signal Processing
- 32-bit, floating point, double precision
- Dynamic Range (A-weighted, unity gain)
- ADC: 114dB
- DAC: 114dB
- CD Input to Analog Output CD: 111dB
- Input to USB Output USB: 114dB
- Input to Analog Output: 114dB
Inputs
- Microphone 1/2 (Combo XLR/ 1/4” [6.35 mm] TRS, Mic/Line switchable)
- Analog Gain: 30 dB (Mic), 4.75 dB (Line)
- Maximum Input: 0.126 Vrms (Mic), 2.3 Vrms (Line)
- Gain Trim: Off to +20dB (unity at center)
- AUX Inputs 1/2 (RCA stereo pairs)
- Maximum Input: 4 Vrms
- Dynamic Range (A-weighted): 114dB
- CD/Phono Inputs 1/2 (RCA stereo pairs, switchable)
- CD: Line
- Maximum Input: 4 Vrms
- Dynamic Range (A-weighted): 114dB
- Phono: RIAA
- RIAA Curve: +0.1/-0.2dB
- Gain (@ 1 kHz): 30dB
- Maximum Input (@ 1 kHz): 126 mV
- Session Input (RCA stereo pair)
- Maximum Input: 4 Vrms
- Dynamic Range (A-weighted): 114dB
Outputs
- Main Outputs (XLR)
- Frequency Response: 20Hz to 20kHz (±0.2dB)
- Maximum Output: 8 Vrms
- THD+N (@ 1kHz, 4 Vrms): 0.002%
- Booth Outputs (1/4"/6.35 mm TRS)
- Frequency Response: 20Hz to 20kHz (±0.2dB)
- Maximum Output: 8 Vrms
- THD+N (@ 1 kHz, 4 Vrms): 0.002%
- Session Outputs (RCA stereo pair)
- Frequency Response: 20Hz to 20kHz (±0.2dB)
- Maximum Output: 4 Vrms
- THD+N (@ 1 kHz, 2 Vrms): 0.002%
- Headphone Outputs (1/4"/6.35 mm and 1/8"/3.5 mm TRS)
- Maximum Output Voltage: 4V (no load)
- THD+N (@ 1 kHz, 2 Vrms): 0.003%
- Output Power: 96 mW (50 ohms)
- Controls: On/Off muting
General
- Display
- Full-color display with capacitive multi-touch
- 2.1” x 3.7”/54 x 95 mm (WxD)
- 4.3”/109 mm (diagonal)
- Pads
- (16) velocity-sensitive multi-color back-lit pads (8 per deck, 10 modes each)
- Faders
- (3) MAG FOUR tension-adjustable faders (2 channel/line faders, 1 crossfader)
- Connectors
- (2) XLR outputs (Main)
- (2) 1/4” (6.35 mm) TRS outputs (Booth)
- (4) RCA stereo input pairs (Deck 1–2)
- (2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2)
- (1) RCA stereo input pair (Session)
- (1) RCA stereo output pair (Session)
- (1) 1/4” (6.35 mm) TRS output (Headphones)
- (1) 1/8” (3.5 mm) TRS output (Headphones)
- (1) 1/4” (6.35 mm) TRS input (Footswitch)
- (2) USB Type-A ports (Deck 1–2 USB Controllers) (2) USB Type-B ports
- (1) IEC power cable input
Power
- Connection: IEC
- Voltage: 100-240V, 50/60Hz
- Consumption: 30W
- Dimensions (WxDxH): 11.2" x 17.5" 4.13". 285 x 445 x 105 mm
- Weight: 12.3 lb. 5.6 kg
